SNOW MOBILE TRAILERS
Here are examples of our latest snow mobile trailers
Please contact us with your specific requests, and we will prepare a free estimate.
Or for more information, call us at:  780-4790604

Or send inquiries to:
   12605-66st
   edmomton, Alberta t5b-1k5
We build single axle Quad Trailers in three weight classes
2,000 LB GVW


4 " CHANNEL IRON SUB FRAME

2" X 3" TUBE IRON TOP DECK

3,500 LB AXLE C/W 5 ON 4.5 IDLER HUBS

​2" BALL COUPLER 5.000 LB RATED

5,000 LB SWING AWAY JACK

V FRONT FOR DRIVE OFF

STAKE POCKETS & RUB RAIL

1 - 4' X 6' RAMP

OR 2 - 1' X 6' RAMPS

 FLUSH MOUNT MARKER & TAIL LIGHTS

2" X 6" WOOD DECK

BUILT IN SIZES

DECK WIDTH FROM 7' TO 8'

DECK LENGTH FROM 10' TO 14'
3,500 LB GVW


4 " CHANNEL IRON SUB FRAME

2" X 3" TUBE IRON TOP DECK

 3,500 LB AXLE C/W 10" X 2 1/4 ELEC. BRAKES 5 ON 4.5HUB DRUMS

​2" BALL COUPLER 5.000 LB RATED

5,000 LB SWING AWAY JACK

V FRONT FOR DRIVE OFF

STAKE POCKETS & RUB RAIL

1' - 4' X 6' RAMP

OR 2 - 1' X 6' RAMPS

 FLUSH MOUNT MARKER & TAIL LIGHTS

2" X 6" WOOD DECK

BUILT IN SIZES

DECK WIDTH FROM 7' TO 8'

DECK LENGTH FROM 10' TO 14'
5,000 LB GVW


5 " CHANNEL IRON SUB FRAME

2" X 3" TUBE IRON TOP DECK

  6,000 LB AXLE C/W 12" X 2" ELEC. BRAKES 6 ON 5.5HUB DRUMS

​2" BALL COUPLER 5.000 LB RATED

5,000 LB DROP FOOT JACK

V FRONT FOR DRIVE OFF

STAKE POCKETS & RUB RAIL

4' X 6' RAMP

OR 2 - 1' X 6' RAMPS

 FLUSH MOUNT MARKER & TAIL LIGHTS

2" X 6" WOOD DECK

BUILT IN SIZES

DECK WIDTH FROM 7' TO 8'

DECK LENGTH FROM 10' TO 14'
